Pemtron

PEMTRON develops equipment used invarious fields such as SMT, Automotive, Battery Terminals and Semiconductors; providing Solder Paste Inspection Equipment (3D SPI), Component Assembly Inspection Equipment (3D AOI, 3D MOI), 3D Wafer Inspection Equipment, 3D Wire Bonding Inspection Equipment and Lead Process and Inspection Equipment Tab.

To download the files you need to Sign In or Sing Up

BackEnd Inspection Equipment


EAGLE 8800 THL​

Features

  • The most advanced 3D Technology
  • Stable and accurate 3D generation with multiple projectors
  • Formation of realistic 3D images
  • High image quality for inspection
  • Simultaneous inspection with 3D and 2D algorithms on all components
  • Telecentric lenses for greater precision and detection
  • Friendly and intuitive GUI
  • Pin Library Tools
  • Offline Debugging Stations in Real Time
  • Great Clearence on Top & Bottom (100mm)

EAGLE 8800 THL TWIN (Top & Bottom)​

Features

  • Simultaneous and Asynchronous 3D Top and Bottom Inspection
  • Combined inspection of SMT on
  • Top and TH on Bottom
  • Stable and accurate 3D generation with multiple projectors
  • Formation of realistic 3D images
  • Improved repeatability
  • Simultaneous inspection with 3D and 2D algorithms on all components
  • Telecentric lenses for greater precision and detection
  • High Speed Processing in Cameras and CPU
  • Friendly and intuitive GUI
  • High Speed Linear Motors

TROI 8800 CI Series​

Features

  • Debugging and Auto-Programming Tools – Through a Golden PCB, the program can be created automatically
  • Reliable Conformal Inspection
  • Detection of process defects such as cracks, lack of coverage, contamination, variation in application (excess or lack) in just seconds
  • Thickness Inspection – Optional
    • Inspection of both sides with different options:
    • Internal inverter for inspection of both sides within the same equipment
    • Simultaneous and Asynchronous
  • Inspection of Both Sides
  • Inspection capabilities:
  • Conformal Coverage
  • Specification of Conformal Free Areas
  • Bubbles
  • Foreign materials
  • Angle Cameras
